Açıklama
The pump with multi-vane impeller ensures maximum operating reliability. The components are pre-assembled for final assembly on site. Including openings for inlet. – tank made of PE, resistant to domestic wastewater – with a pedestrian class cover plate made of polymer – including backflow preventer for the pressure pipe – including openings for inlet, ventilation and cable duct – pump/s with multi-vane impeller for maximum operating reliability
Variant
Type of system: Single unit
Installation: Wet installation
Pump control: Float switch
Backflow preventer: integrated
General characteristics
Colour: black
Standard: EN 12050-2
Type of wastewater: without sewage
Installation situation: underground installation
Delivery state: Pre-mounted for final assembly on site (pumps and sensor system must be fitted on site and control unit must be connected)
System type: Mono
Dimensions
Net weight: 26 kg
Gross weight: 32 kg
Installation depth: 0 – 830 mm
Length: 590 mm
Width: 590 mm
Height: 830 mm
Packaging dimension: length: 800 mm
Packaging dimension: width: 700 mm
Packaging dimension: height: 950 mm
Tank/drain body
Pressure pipe connection (DN): 50
Pressure pipe connection (OD): 63 mm
Inlet max. scoring (DN): 100 mm
Pumping volume: 25 l
Coverage features
Type of cover: Round cover plate
Colour of cover: black
Width of cover: 600 mm
Length of cover: 615 mm
Locking: lockable
Load class: up to 300 kg
Pumping device
Pump: GTF 1250
Number of pumps: 1
Weight, pump: 10 kg
Connection type: Schuko (earthed contact) 2-pin
Rated current: 5,4 A
Protection class: I
Insulation class: F
Protection class (pump): IP 68 (3m)
Temperature monitoring: integrated
Max. temperature (permanent) of conveyed material: 40 °C
Max. pumping capacity: 20 m³/h
Max. pumping height: 11 m
Speed: 2700 U/min
Power P1: 1,3 kW
Power P2: 0,8 kW
Operating mode: S3 – 50 %
Type of fuse required (electrical protection): C 16 A
Type of pump connection cable: H07RN-F 3G 1.5 mm²
Impeller type: Multi-vane impeller
Free passage: 30 mm
Switching level, float switch OFF: 160
Switching level, float switch ON: 260
Length of mains cable for pump: 10 m
Control
Motor protection switch: yes
Level measurement instrument: Float switch
Mains frequency: 50 Hz
Operating voltage: 230 V
Connection type: Schuko (earthed contact) 2-pin
Length of mains cable for control unit: 1,45 m
Type of fuse required (electrical protection): C 16 A
