Açıklama
Variant
Direction of flow: left
Disposal variant: Standard
Shredder-Mix-System: no
Inspection window: yes
Nominal size (NS): 15
SonicControl: no
Refill inlet in accordance with DIN 1988: yes
Type of disposal: manual with suction hose
General characteristics
Installation situation: free-standing installation
Delivery state: Installation-ready (connection parts must be connected on site)
Dimensions
Net weight: 355 kg
Gross weight: 430 kg
Set-up area, length: 3530 mm
Set-up area, width: 1680 mm
Set-up area, height: 1950 mm
Required access area, length: 3530 mm
Required access area, width: 1490 mm
Required access area, height: 1950 mm
Packaging dimension: length: 3530 mm
Packaging dimension: width: 1490 mm
Packaging dimension: height: 2085 mm
Tank/drain body
Distance pipe bottom outlet to tank bottom: 1130 mm
Distance pipe bottom inlet to tank bottom: 1200 mm
Outlet nominal size (OD): 200 mm
Outlet nominal size (DN): 200 mm
Inlet nominal size (OD): 200 mm
Inlet nominal size (DN): 200 mm
Coverage features
Type of cover: Cover
Cover material: Polymer
Colour of cover: violet
Tightness: odour-tight
Wastewater contents
Separator contents: 2230 l
Max. grease layer thickness: 180 mm
Total volume: 3730 l
Contents of sludge trap: 1500 l
Storage quantity of grease: 600 l
