Açıklama
Variant
Type of system: Single unit
Pump control: Float switch
Backflow preventer: integrated
General characteristics
Colour: black
Standard: EN 12050-2
Type of wastewater: without sewage
Installation situation: floor slab installation
Delivery state: Installation-ready (connection parts must be connected on site)
System type: Mono
Dimensions
Net weight: 17,47 kg
Gross weight: 28 kg
Groundwater resistant from lower edge of base section: 3000 mm
Installation depth: 490 – 620 mm
Type of height adjustability: vertically adjustable upper section
Length: 617 mm
Width: 585 mm
Packaging dimension: length: 590 mm
Packaging dimension: width: 590 mm
Packaging dimension: height: 675 mm
Tank/drain body
Pressure pipe connection (DN): 32
Pressure pipe connection (OD): 40 mm
Inlet nominal size (DN): 100 mm
Pumping volume: 16 l
Coverage features
Type of cover: tileable cover plate
Cover material: Polymer
Colour of cover: silver grey
Width of cover: 366 mm
Length of cover: 366 mm
Drainage function: yes
Locking: Lock & Lift
Load class: K 3 (EN 1253-1)
Max. flooring height: 16 mm
Pumping device
Pump: GTF 1200
Number of pumps: 1
Connection type: Schuko (earthed contact) 2-pin
Operating voltage: 230 V
Protection class (pump): IP 68 (3m)
Temperature monitoring: integrated
Max. temperature (permanent) of conveyed material: 40 °C
Hot water resistance for a short time (2 min): 80 °C
Max. pumping capacity: 15,5 m³/h
Max. pumping height: 9 m
Speed: 2650 U/min
Power P1: 1,4 kW
Power P2: 0,84 kW
Operating mode: S3 – 10 %
Type of pump connection cable: H07RN-F 3G 1.5 mm²
Impeller type: Multi-vane impeller
Free passage: 30 mm
Type of fuse required (electrical protection): C 16 A
Length of mains cable for pump: 5 m
Rated current: 6,2 A
Control
Level measurement instrument: Float switch
Type of level measurement: mechanical
Mains frequency: 50 Hz
Operating voltage: 230 V
Connection type: Schuko (earthed contact) 2-pin
