Açıklama
Dimensions
Net weight: 15 kg
Gross weight: 15,45 kg
Packaging dimension: length: 420 mm
Packaging dimension: width: 420 mm
Packaging dimension: height: 340 mm
Pumping device
Pump: SPZ 1000
Number of pumps: 1
Weight, pump: 10 kg
Connection type: coded plug
Rated current: 5,2 A
Protection class: I
Insulation class: F
Cos phi – power factor: 0,97
Protection class (pump): IP 68 (3m/48h)
Temperature monitoring: integrated
Max. temperature (permanent) of conveyed material: 40 °C
Max. pumping capacity: 11,5 m³/h
Max. pumping height: 10 m
Speed: 2800 U/min
Power P1: 1,2 kW
Power P2: 0,69 kW
Operating mode: S3 – 50 %
Type of fuse required (electrical protection): C 16 A
Type of pump connection cable: H07RN-F 3G 1.5 mm²
Impeller type: Macerator
Length of mains cable for pump: 5 m
Control
Control unit: Comfort
Standby power: 5 W
Alarm sensor: optical probe
Level measurement instrument: optical probe
Type of level measurement: optical
Protection class control unit: IP 54
Operating voltage: 230 V
Connection type: coded plug
Length of mains cable for control unit: 1,4 m
Potential-free contact: yes
GSM interface: no
USB interface: no
Log book function: yes
Multi-line display: yes
Battery buffering: yes
Self-diagnosis system (SDS): yes
Type of fuse required (electrical protection): C 16 A
