Installation
For free standing installation
Consisting of:
Integrated sludge trap and self-actuated closure lock,
calibrated for light liquids with densities between 0.85
to 0.95 g/cm3. With removable coalescence filter
insert. Completely water tight to top of cover,
resistant against aggressive wastewaters, certified
structural test. Corrosion free HDPE
Inlet and outlet Ø ….. for connection pipes:
PE-HD (according to EN 12666-1),
PVC pipe (according to EN 1401-1), PP or AS.
Delivery: Completely assembled
